1.Wide view and High Strength Lifting System

Excellent front view which is benefit for the work safety improvement and working efficiency is provide with wide view mast which has proprietary intellectual property and fork positioner.

2.High voltage lithium battery system

The truck is equipped with independent high-power fast charging interface;

The high voltage lithium battery is arranged up and down, which is convenient for assembly and replacement;

Lithium battery has high discharge rate, high cell energy density,longer battery life and stronger power;The distribution box wiring cable port area and the rotary radiator share a detection space, which is more convenient for maintenance and repair;

Lithium battery intelligent fire protection system is equipped as standard to improve the safety of use;It only takes 1-2 hours to charge the battery fully.

3.Proportional variable hydraulic braking system of quadruple pump

The compound variable hydraulic system has higher integration, more energy saving and faster system response,

Proportion control on the hydraulic main action of the whole truck has a wider range of performance parameters, which is suitable for different operation application;

Motor speed adaptive system has more flexible steering and higher efficiency,

The intelligent pump motor integrates multi-channel heat dissipation system to ensure the reliable and lasting work of the whole hydraulic,transmission and power system.

4.Wet drive axle

Wet braking system is adopted, which has stable working performance and is free from the influence of external moderation and dust maintenance free, and greatly reduces the maintenance cost, The friction plate is immersed in oi for cooling, which can significantly reduce the working temperature, significantly improve the braking performance and service life of the braking system, and can meet the requirements of frequent braking occasions with long time, high strength and short distance such as in cabin, smelting plant.

5.Intelligent safety

Intelligent digital display instrument monitors the overall status of the whole truck and ensures the safety of the truck operation;

Intelligent temperature management system realize real-time thermal management in different zone and ensures the proper working temperature of the truck;

Intelligent fire protection system offers high safety protection;

Intelligent mast height angle detection safety control system improves driving safety;

Intelligent visual reverse radar monitoring system provides all-round safety protection.
